Choosing a pump foil front wing: area, span and aspect ratio

What the three numbers on every spec sheet mean for pumping, and how to pick a size for your weight.

1 min read

A rider flying a foil board close to the beach

Every front wing in our catalog lists three numbers first: area, span and aspect ratio. Together they tell you most of what a wing will do on a pump session.

Area: how much lift

Area, in cm², sets how slowly you can fly. More area takes off earlier and forgives a slow pump. Most riders pump on 900–1,400 cm²; heavier riders and dock starts sit at the top of that range.

Span: how far it glides

Span, in mm, is the width tip to tip. A wider wing glides further between pumps and links bumps more easily, but turns wider.

Aspect ratio: efficiency

Aspect ratio is span squared divided by area. Wings around 8 are forgiving and easy to start on; 10–13 is where efficient pumping and long glides live, at the cost of a narrower sweet spot.

Use the catalog filters to narrow front wings by area, span and aspect ratio, then compare up to four side by side.

Gear in this guide

Open the catalog

Axis Foils

Axis ART v2 999

Area
1,038 cm²
Span
999 mm
AR
9.9

RRP

€759

1 used

from €631

Takuma

Takuma Kujira II 1095

Area
1,095 cm²
Span
956 mm
AR
8.3

RRP

€849

1 used

from €520

Code Foils

Code Foils 1250R

Area
1,250 cm²
Span
1,275 mm
AR
13

RRP

€1,290

1 used

from €1,124
